If the land area falls between 1 to 5 Acre you are recommended to go for small Raingun system. You have to decide permanent or temporary system erection according to the crop pattern and your convenience. Raingun are only suitable for small and medium area. Uniform sprinkling, more area coverage than sprinkler system is convenience for this is size.
We have Many Model Rainguns to suite individual irrigation requirements. Here we shows Popular widely used few models.
Suitable Sprinkler Models and its Specifications
| 1. Inlet Size | : | 1 Inch |
| 2. Pressure | : | 1.5 to 4 Kg/cm2 |
| 3. Discharge | : | 72 to 150 LPM |
| 4. Suitable For | : | Sugarcane, Groundnuts, Fodder Crops, Coffee Tea Plants, Vegetables |
| 5. Working Method | : | Half Circle and Full Circle |
| 6. Area Coverage | : | 65 Feet Radius at 3.5 kg/cm2 |
| 7. Nozzle Size | : | 7mm, 8mm, and 10mm |
| 8. 7.5 HP Motor Runs | : | 8 Rainguns Based on Pressure and Discharge |
| 1. Inlet Size | : | 1.25 Inch |
| 2. Pressure | : | 1.5 to 3 Kg/cm2 |
| 3. Discharge | : | 100 to 280 LPM |
| 4. Suitable For | : | Sugarcane, Groundnuts, Fodder Crops and Vegetables |
| 5. Working Method | : | Half Circle and Full Circle |
| 6. Area Coverage | : | 75 Feet Radius at 3 kg/cm2 |
| 7. Nozzle Size | : | 8mm,10mm,12mm,14mm |
| 8. 5 HP Motor Runs | : | 1 or 2 Rainguns Based on Pressure and Discharge |
Normally Raingus are nothing but an upgraded Sprinkler. Due to its huge area coverage and Quick wetting, its getting popular these days. The Performance of the Raingun based on the Pressure and Discharge of the Pump which we are using. High Durability, Uniform Wetting and Taking less time for irrigation are the Unique Features of Rainguns.
| 1. Inlet Size | : | 1.5 Inch |
| 2. Pressure | : | 2.5 to 4 Kg/cm2 |
| 3. Discharge | : | 180 to 420 LPM |
| 4. Suitable For | : | Sugarcane, Groundnuts, Fodder Crops, Coffee Tea Plants, Vegetables |
| 5. Working Method | : | Half Circle and Full Circle |
| 6. Area Coverage | : | 90 Feet Radius at 3.5 kg/cm2 |
| 7. Nozzle Size | : | 10mm,12mm,14mm and 16mm |
| 8. 7.5 HP Motor Runs | : | 1 to 3 Rainguns Based on Pressure and Discharge |
| 1. Inlet Size | : | 1.5 Inch |
| 2. Pressure | : | 3 to 5 Kg/cm2 |
| 3. Discharge | : | 240 to 440 LPM |
| 4. Suitable For | : | Deligate Crops,Flowers,Chilly,Tomato,Onion,Sugarcane. |
| 5. Working Method | : | Half Circle and Full Circle with Automatic Jet Breaking Mechanism |
| 6. Area Coverage | : | 100 Feet Radius at 3.5 kg/cm2 |
| 7. Nozzle Size | : | 12mm,14mm,16mm and 18mm |
| 8. 7.5 HP Motor Runs | : | Only One Raingun |
By using gear driven mechanism, it develops more Mist than any other raingun. So it mainly used for Deligate crops like Flower, Chilly, Tomato, Onion, Sugarcane, Groundnut etc., Less maintanance and the durability are the another features of this model.
