In dairy sectors waste water management is the challengeable work.This consumes much more time and labour.We offer better solution for this problem.single phase 1 hp to 2 hp sewage mud pump introduced for this application to handle 20mm to 50mm solids.It works with 12000 lph discharge and 40 feet head.so you can pump waste slurry up to 1000 feet Horizontal distance by using 2 or 2.5 inch PVC or HDPE pipes.
By using our own designed sewage mud pump you can pump with semi solids up to the diameter of 40 mm and fibre particle easily pumped out without lock. Because all solid materials never contact with our specially designed impeller technology.. One more special in our pump is, we develop this pump with various working situations to eliminate all the problems by solid handling.
| 1. Power | : | Single Phase 1 HP. |
| 2. Motor | : | Submersible Type. |
| 3. Discharge | : | 1200 LPH. |
| 4. Total Head | : | 12 Meter Max. |
| 5. Pumping Distance | : | Upto 1000 Feet at 20 Feet Elevation. |
| 6. Solid Handling Capacity | : | 20mm to 50mm. |
| 7. Impeller Used | : | U Type Or Helical. |
| 8. Motor Protection for | : | Dry Run, Over Heat, Impeller Lock. |
| 9. Seal Used | : | Oil Immersed Carborundum. |
| 10. Outlet Delivery | : | 2 Inch. |
